CASSIA

[English](/CASSIA/) | [中文](/CASSIA/README_CN.html)

CASSIA (Collaborative Agent System for Single-cell Interpretable Annotation) is a tool that enhances cell type annotation using multi-agent Large Language Models (LLMs).

🌐 CASSIA Web UI (cassia.bio) - Try CASSIA’s core features online. For a comprehensive experience with all advanced features, use our R or Python package.

📚 Complete Documentation/Vignette (docs.cassia.bio)

🤖 LLMs Annotation Benchmark (sc-llm-benchmark.pages.dev)

📰 News

2026-04-08 🐛 Bug fix released — please update to the latest version (v1.3.7). A recent change to CASSIA’s networking layer introduced an issue that could cause some users to see errors when running annotations. This is now fixed.

R / Python users: update to v1.3.7 — remotes::install_github("ElliotXie/CASSIA/CASSIA_R", force = TRUE, upgrade = "never") or pip install --upgrade cassia

Web users: open cassia.bio in an incognito window (or clear your browser cache) to pick up the new build.

If you still see an error after updating, please open an issue.

📜 Previous Updates (click to expand)

> **2025-11-29** >🎇 **Major update with new features and improvements!** > - **Python Documentation**: Complete Python docs and vignettes now available > - **Annotation Boost Improvements**: Sidebar navigation, better reports, bug fixes > - **Better Scanpy Support**: Fixed marker processing, improved R/Python sync > - **Symphony Compare Update**: Improved comparison module > - **Batch Output & Ranking**: Updated HTML output for runCASSIA_batch with new ranking method option > - **Fuzzy Model Aliases**: Easier model selection without remembering exact names > **2025-05-05** > 📊 **CASSIA annotation benchmark is now online!** > The latest update introduces a new benchmarking platform that evaluates how different LLMs perform on single-cell annotation tasks, including accuracy and cost. > **LLaMA4 Maverick, Gemini Flash, and DeepSeek V4 Flash** are highly cost-effective options. > 🔧 A new **auto-merge** function unifies CASSIA output across different levels, making subclustering much easier. > 🐛 Fixed a bug in the annotation boost agent to improve downstream refinement. > **2025-04-19** > 🔄 **CASSIA adds a retry mechanism and optimized report storage!** > The latest update introduces an automatic retry mechanism for failed tasks and optimizes how reports are stored for easier access and management. > 🎨 **The CASSIA logo has been drawn and added to the project!** > **2025-04-17** > 🚀 **CASSIA now supports automatic single-cell annotation benchmarking!** > The latest update introduces a new function that enables fully automated benchmarking of single-cell annotation. Results are evaluated automatically using LLMs, achieving performance on par with human experts. > **A dedicated benchmark website is coming soon—stay tuned!**

🏗️ Installation

Python and CLI

pip install --upgrade cassia
cassia doctor
cassia examples --out cassia_example

The installed CLI supports API backends and local Codex, Claude Code, Cursor, OpenCode, or custom-shell agents. Run cassia help to see one-shot, validated, Fused Boost, subcluster, consensus, stable Judge, and optional Seurat agent workflows. See the Python CLI guide and the release benchmark snapshot.

Integrated Seurat clustering and annotation is available through cassia agent auto. It runs short-lived, versioned R transactions by default—no daemon is required—and supports fixed, conservative, and adaptive topology policies. For example: cassia agent auto object.rds --out runs/conservative --strategy conservative --backend codex-cli --model gpt-6-astra --reasoning-effort high. Use cassia agent compare RUN... to compare audited edit, fragmentation, QA, and labeled-cell coverage metrics without another LLM call.

R

# Install dependencies
install.packages("devtools")
install.packages("reticulate")

# Install CASSIA
devtools::install_github("ElliotXie/CASSIA/CASSIA_R")

If you have network issues installing from GitHub, you can install from source:

# Install from downloaded source package
install.packages("path/to/CASSIA_1.3.2.tar.gz", repos = NULL, type = "source")

Download source package: CASSIA_1.3.2.tar.gz

Note: If the environment is not set up correctly the first time, please restart R and run the code below

library(CASSIA)
setup_cassia_env()

🔑 Set Up API Key

It should take about 3 minutes to get your API key.

You only need one API key to use CASSIA. We recommend OpenRouter since it provides access to most models (OpenAI, Anthropic, Google, etc.) through a single API key — no need to sign up for multiple providers.

# For OpenRouter
setLLMApiKey("your_openrouter_api_key", provider = "openrouter", persist = TRUE)

# For OpenAI
setLLMApiKey("your_openai_api_key", provider = "openai", persist = TRUE)

# For Anthropic
setLLMApiKey("your_anthropic_api_key", provider = "anthropic", persist = TRUE)

# For custom OpenAI-compatible APIs (e.g., DeepSeek)
setLLMApiKey("your_deepseek_api_key", provider = "https://api.deepseek.com", persist = TRUE)

# For local LLMs - no API key needed (e.g., Ollama)
setLLMApiKey(provider = "http://localhost:11434/v1", persist = TRUE)

Custom APIs: CASSIA supports any OpenAI-compatible API endpoint. Simply use the base URL as the provider parameter.

Local LLMs: For data privacy and zero API costs, use local LLMs like Ollama or LM Studio. No API key required for localhost URLs.

API Provider Guides:

🧬 Example Data

CASSIA includes example marker data in two formats:

# Load example data
markers_unprocessed <- loadExampleMarkers(processed = FALSE)  # Direct Seurat output
markers_processed <- loadExampleMarkers(processed = TRUE)     # Processed format

⚙️ Quick Start

# Core annotation
runCASSIA_batch(
    marker = markers_unprocessed,                # Marker data from FindAllMarkers
    output_name = "cassia_results",              # Output file name
    tissue = "Large Intestine",                  # Tissue type
    species = "Human",                           # Species
    model = "anthropic/claude-sonnet-5",         # Model to use
    provider = "openrouter",                     # API provider
    max_workers = 4                              # Number of parallel workers
)

Want even better results? Use runCASSIA_pipeline() which adds automatic quality scoring and the AnnotationBoost agent for difficult clusters. See complete documentation for details.

🤖 Supported Models

You can choose any model for annotation and scoring. CASSIA also supports custom providers (e.g., DeepSeek) and local open-source models (e.g., gpt-oss:20b via Ollama).

The current defaults are listed below. They are compatibility recommendations, not new CASSIA benchmark results; the dated benchmark entries above remain historical records.

OpenAI

gpt-6-astra: Current flagship for the hardest workloads (availability may vary)
gpt-5.6-terra: Balanced default (Recommended)
gpt-5.6-luna: Fast, cost-sensitive option
gpt-4o: Used in the benchmark

OpenRouter

anthropic/claude-sonnet-5: Balanced default (Recommended)
openai/gpt-6-astra: Current OpenAI flagship
openai/gpt-5.6-terra: Balanced OpenAI option
google/gemini-3.8-flash: Fast, low-cost option
deepseek/deepseek-v4-flash-0731: Very low-cost option
x-ai/grok-4.6, moonshotai/kimi-k3, and meta-llama/llama-4-maverick are also supported

Anthropic

claude-sonnet-5: Balanced default (Recommended)
claude-opus-5: Current flagship
claude-haiku-4-5: Fast option

Other Providers

These models can be used via their own APIs. See Custom API Providers for setup.

deepseek-v4-flash or deepseek-v4-pro (DeepSeek V4). Provider: https://api.deepseek.com
glm-5.1 (GLM 5.1). Provider: https://api.z.ai/api/paas/v4/

Local LLMs

gpt-oss:20b: Can run locally via Ollama. Good for large bulk analysis with acceptable accuracy. See Local LLMs for setup.

📖 Citation

📖 Read our paper in Nature Communications

Xie, E., Cheng, L., Shireman, J. et al. CASSIA: a multi-agent large language model for automated and interpretable cell annotation. Nat Commun (2025). https://doi.org/10.1038/s41467-025-67084-x

📬 Contact

If you have any questions or need help, feel free to email us. We are always happy to help: xie227@wisc.edu If you find this project helpful, please share it with your friends, and give this repo a star ⭐ Many thanks!
