CASSIA
Collaborative Agent System for Single-cell Interpretable Annotation
A tool that enhances cell type annotation using multi-agent Large Language Models (LLMs).
Key Resources
News
📊 CASSIA annotation benchmark is now online!
The latest update introduces a new benchmarking platform that evaluates how different LLMs perform on single-cell annotation tasks, including accuracy and cost.
LLaMA4 Maverick, Gemini 2.5 Flash, and DeepSeekV3 are the top three most balanced options—nearly free!
🔧 A new auto-merge function unifies CASSIA output across different levels, making subclustering much easier.
🐛 Fixed a bug in the annotation boost agent to improve downstream refinement.
🔄 CASSIA adds a retry mechanism and optimized report storage!
The latest update introduces an automatic retry mechanism for failed tasks and optimizes how reports are stored for easier access and management.
🎨 The CASSIA logo has been drawn and added to the project!
🚀 CASSIA now supports automatic single-cell annotation benchmarking!
The latest update introduces a new function that enables fully automated benchmarking of single-cell annotation. Results are evaluated automatically using LLMs, achieving performance on par with human experts.
A dedicated benchmark website is coming soon—stay tuned!
Installation
# Install dependencies
install.packages("devtools")
install.packages("reticulate")
# Install CASSIA
devtools::install_github("ElliotXie/CASSIA/CASSIA_R")Note: If the environment is not set up correctly the first time, please restart R and run the code below
library(CASSIA)
setup_cassia_env()🔑 Set Up API Keys
It should take about 3 minutes to get your API key.
We recommend starting with OpenRouter since it provides access to most models through a single API key.
# For OpenRouter
setLLMApiKey("your_openrouter_api_key", provider = "openrouter", persist = TRUE)
# For OpenAI
setLLMApiKey("your_openai_api_key", provider = "openai", persist = TRUE)
# For Anthropic
setLLMApiKey("your_anthropic_api_key", provider = "anthropic", persist = TRUE)API Provider Guides:
For Python tutorial, please visit here.
Quick Start
🧬 Example Data
CASSIA includes example marker data in two formats:
# Load example data
markers_unprocessed <- loadExampleMarkers(processed = FALSE) # Direct Seurat output
markers_processed <- loadExampleMarkers(processed = TRUE) # Processed format⚙️ R Pipeline
# The default provider is set to OpenRouter.
runCASSIA_pipeline(
output_file_name, # Base name for output files
tissue, # Tissue type (e.g., "brain")
species, # Species (e.g., "human")
marker, # Marker data from findallmarker
max_workers = 4 # Number of parallel workers
)📤 Output
The pipeline generates the following files:
Annotation Results
CSV files containing cell type annotations for each cluster
Annotation Report
Interactive HTML report with detailed annotation reasoning
Annotation Boost Report
HTML report for optimized annotations
Supported Models
You can choose any model for annotation and scoring. Some classic models are listed below. OpenRouter supports most of the current popular models, although some have not been extensively benchmarked in the CASSIA paper — feel free to experiment with them.
OpenRouter
- google/gemini-2.5-flash-preview: One of the best-performed low-cost models, comparable with models like gpt-4o (Most recommended)
- deepseek/deepseek-chat-v3-0324: One of the best-performed open-source models, turns to gives very detailed annotations (Recommended)
- deepseek/deepseek-chat-v3-0324:free: Free but slower
OpenAI
- gpt-4o: Used in the benchmark
Anthropic
- claude-3-7-sonnet-latest: The latest High-performance model
Troubleshooting
Authentication (Error 401)
# Check if API key is set correctly
key <- Sys.getenv("ANTHROPIC_API_KEY")
print(key) # Should not be empty
# Reset API key if needed
setLLMApiKey("your_api_key", provider = "anthropic", persist = TRUE)File Errors
- Use absolute paths when necessary
- Check file permissions
- Ensure files aren't open in other programs
Best Practices
- Keep API keys secure
- Maintain sufficient API credits
Note: This website covers only basic CASSIA functionality. For a complete tutorial including advanced features and detailed examples, please visit: CASSIA Complete Tutorial.
Citation
CASSIA: a multi-agent large language model for reference-free, interpretable, and automated cell annotation of single-cell RNA-sequencing data
Elliot Xie, Lingxin Cheng, Jack Shireman, Yujia Cai, Jihua Liu, Chitrasen Mohanty, Mahua Dey, Christina Kendziorski
bioRxiv 2024.12.04.626476; doi: https://doi.org/10.1101/2024.12.04.626476
Contact
If you have any questions or need help, feel free to email us. We are always happy to help:
If you find this project helpful, please share it with your friend, and give this repo a star ⭐. Many thanks!
